Instructions | Wahoo KICKR 142x12 Adapter

Product Information

The KICKR 142X12 Mountain Bike Adapter is a conversion kit designed to enable mountain bikes of the 12x142mm size to be secured to the KICKR.

NOTE: The KICKR is not compatible with the through axle itself; instead, this adapter kit is used to secure the bike in place. Please watch the installation video before attempting to install yourself (https://www.youtube.com/watch?v=Bd25LHeSndY) . This is for 12x142mm bikes only. Not compatible with 12x135, 12x150, or any other through axle system.

This product is shipped with the following:

Threaded Axle Spacer
Hub Width Adapter
Conical Axle Adapter
Flat Axle Adapter
XL Quick Release Skewer
Extended Quick Release Nut

Setup

How to install the adapter:

NOTE: Before installing the adapter, you will need to remove the existing quick release and R130/M135 hub adapter from your KICKR. Additionally, remove the two springs threaded on the quick release from the adapter kit, as they will not be required.

Install the 12x142mm hub adapter on the non-drive side (label facing out) of your KICKR. Thread the axle washer on the drive side of your KICKR. Gently tighten with a 17mm wrench if required.
Lower the bicycle rear dropouts onto the KICKR. Lift the front wheel slightly to ensure the bicycle is seated on the KICKR correctly.
Select either the conical (a) or flat (b) frame adapter and thread on the quick release skewer before installing on the KICKR with the included skewer nut.
Lock in place by lifting on the quick release lever.

Troubleshoot

Having trouble? Contact support for more information.

Product Care Information:

Should any of the Adapter parts require cleaning, use a moist soft cloth or similar to re-move any debris.
